MDG ATMe Hazer Industrial grade CO2 or N2 only

MDG ATMe Hazer

Industrial grade CO2 or N2 only

Varenr: 922-10010
68 565,-eks mva.
Logg inn for å se dine nettopriser.
Ikke kunde? Søk om kundestatus.
Ikke på lager (6 dager)
BeskrivelseTeknisk infoTilbehørDokumenter
Beskrivelse
  • LOWEST FLUID CONSUMPTION ON THE MARKET

    At 1.38 bar (20 psi) ATMe uses only 55 ml (1.86 oz) of fluid per hour to give a total running time of 46 hours from its 2.5 L (0.66 US gallon) reservoir.

  • LONGEST HANGING TIME

    Our MDG Neutral fluid is specially created for the longest hanging time.

  • VARIABLE HAZE OUTPUT

    0-100% haze output control from your DMX / RDM device. 100% duty cycle.

  • APS™ (AUTOMATIC PURGING SYSTEM)

    This system purges the heating module after the first heating cycle and after every emission of haze preventing residual build up and clogging.

  • NUMEROUS CONTROL OPTIONS

    4-button LCD user interface, 3 standard USITT DMX512 channels, XLR-5 connectors, RDM compliant.

  • EXTREMELY QUIET OPERATION

    Noise emission (at 1m/3.3ft): 45.4 dB in standard mode. The theater mode reduces the fan speed depending on haze output level.

Fluid type (M.S.D.S. available on request): MDG Neutral Fluid
Consumption (per hour at 1.38 bar/20 psi): 55 ml (1.62 oz / 0.0145 US gallon)
Consumption (per hour at 2.76 bar/40 psi): 110 ml (3.24 oz / 0.0290 US gallon)
Gas type: Industrial grade CO2 or N2 only
Consumption (per hour at 1.38 bar/20 psi): 0,18 kg (0.4 lb)
Consumption (per hour at 2.76 bar/40 psi): 0,36 kg (0.79 lb)
Maximum Gas pressure input: 4.14 Bar (60 PSI)
Total running time (per hour at 1.38 bar/20 psi): 46 hours
Total running time (per hour at 2.76 bar/40 psi): 23 hours
Reservoir capacity: 2,5 L (0.66 US gallon)
Haze colour: Pure white
Partical size: 0,5 - 0,7 micron
Warm-up time (maximum): 8 minutes
Control: 4-button LCD user interface
DMX: 4 standard USITT DMX512 channels, XLR-5, 1 input, 1 output
USB: USB 2.0 Link connector (control)
Operating voltage: 100-250 VAC, 50/60 Hz single phase
Power consumption: 715 W
Noise emission (at 1 m/3.3 ft): 45.4 dB (A)
Dimension: Length 68,5 cm (27") Width 18 cm (7") Height 30 cm (12")
Weight: 16.8 kg (37 lb)
Approval: CE, CSA and UL

Teknisk info

Produktinformasjon

Type Hazer
