SPECIFICATIONS:
Source
• Light Source: RGB SMD1921 LED
• Pixel Density: 150x150 per panel; 67816 per square meter
• Operating Life / MTBF: 50,000 Hours / 5,000 Hours
• Pixel Pitch: 3.84mm
• Gaps<0.5mm
Optics
• Brightness: 4500 NITS
• View Angle: Horizontal 160°/Vertical 140° @ 3m
• Gray Scale: ≥14-bit
• Brightness Adjustment: 0~100% 100 Levels
• Contrast ratio: 5000:1
• Display Color: 256
• Processing: 14-bit
Control
• Control Mode: Novastar Synchronous System
• Refresh Rate: 3840Hz
• Control Distance: Ethernet Cable <120m
• Optional Novastar Sending Cards and Accessories available
• Frame Update Frequency: 50-75Hz
• Brightness Correction: Pixel, Module, Cabinet
Colors
• RGB
Construction
• Protection Level: IP65 Front / IP54 Back
• Aluminium Frame with built-in corner protectors
• Module Quantity: 4
• IP65 Front / IP54 Back (Temporary outdoor use)
• Curve panels in convex or concave -6, -3 degrees or 0,
+3, +6 degrees
• Quick lock system to connect panels together
• Quick release power supply / receiving card module
Electrical
• Multivoltage 100-240V 50/60Hz
• Max. Power Consumption: 210W/per panel
• Ave. Power Consumption: 84W/per panel
• Operational temperature: -20 to +40 degrees
• Operational humidity: 10% — 90% (no condensation)
Connections
• Locking IP65 RJ45 In/Out connections
• Locking IP65 Power In/Out connections
Dimensions & Weight
• Dimensions (LxWxH): 576 x 76.8 x 576 mm
• Weight: 9kg.
What’s included
• Locking IP65 RJ45 Cabinet to Cabinet Data Link Cables
• Locking IP65 Power Link Cables
Optional Accessories
• 1521000306 ADJ Touring Case 8x VS3IP/AV6: Flight Case – Fits 8 VS3IP Panels
• 1226300161 VS3IPRB1: Rigging Bar – Hang up to 20 VS3IP Video Panels vertically or ground stack up to 8
• VS1RSB Rear Support Bracket for VS Series Panels
• 1226300156 VSRQR: Quick Rig - Attaches and locks on to the rear of any Vision series panel so it can be fastened to a 2" pipe or truss
• 1226300067 Novastar VX4S: Video Processor
• 1226300034 Novastar MCTRL-300: Video Processor
• Arkaos Media Master: Video Software
• Arkaos GrandVJ 2.0: Video Software
