Blustream SP18CS 8-Way Splitter 8-Way 4K HDMI 2.0 HDCP 2.2 Splitter

Blustream SP18CS 8-Way Splitter

8-Way 4K HDMI 2.0 HDCP 2.2 Splitter

Varenr: SP18CS
5 870,-eks mva.
6 523,-Ordinær pris
Logg inn for å se dine nettopriser.
Ikke kunde? Søk om kundestatus.
Ikke på lager (7 dager)
BeskrivelseDokumenter
Beskrivelse

Description

Our SP18CS 4K HDMI 2.0 splitter distributes a single HDMI source to eight simultaneous outputs with both digital (S/PDIF) and analogue audio breakout.

The splitter supports full HDMI 2.0 and HDCP 2.2 with video resolutions up to and including 4K @ 60Hz 4:4:4 with automatic video down conversion on each output.

Box Contents

1x SP18CS
1x 12V/2A DC power supply
1x Mounting Kit
1x Quick Reference Guide

Key Features

  • Features 1x HDMI input that is replicated to 8x HDMI outputs

  • Supports HDMI 2.0 18Gbps specification including HDR

  • Supports up to 4K UHD 60Hz 4:4:4

    Video down-conversion on outputs allowing a display only capable of supporting lower video resolutions (4K 60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on remaining video outputs

  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K

  • Supports all known HDMI audio formats including Dolby Atmos, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio transmission

  • HDMI audio breakout to analogue L/R audio and optical digital outputs concurrently

  • Advanced EDID management

  • HDCP 2.2 Support

Specifications

  • Video Input Connectors: 1x HDMI Type A

  • Video Output Connectors: 8x HDMI Type A

  • EDID: 4-PIN DIP switch

  • Smart Scale: 8-PIN DIP switch

  • Audio Output Connectors: 1x Digital (Optical), 1x Analogue audio L/R (3.5mm stereo Jack)

  • Dimensions (W x D x H): 300mm x 92mm x 23mm

  • Shipping Weight: 1.3kg

  • Operating Temperature: 32°F to 104°F (0°C to 40°C)

  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)

  • Power Supply: 12V/2A DC
